{Ck}=argmin(L)L=N1k=0|Pkni=0bi,n(tk)Ci|2

tk=dk/dN1,dk=dk1+|PkPk1|

Bernstein basis polynomial: bi,n(t)=(ni)ti(1t)ni=nj=0tjMji

Mji=n!(nj)!(1)j+ii!(ji)!=(1)j+iMjj(ji)(ji)

note:  Mjj=(nj),Mji=0(j<i)

// calculate binomial coefficients using Pascal's triangle
void binomialCoeffs(int n, double** C) {
    // binomial coefficients
    for (int i = 0; i <= n; i++)
        for (int j = 0; j <= i; j++)
            if (j == 0 || j == i) C[i][j] = 1;
            else                  C[i][j] = C[i - 1][j - 1] + C[i - 1][j];
}
std::vector<double> basisMatrix(int degree) {
    const int n = degree + 1;
    std::vector<double* > C(n);
    std::vector<double> Cbuff(n*n);
    for (int i = n; i-->0;)
        C[i] = &Cbuff[i * n];
    // C[degree, k]; k=0,..,degree)
    binomialCoeffs(degree, &C[0]);
    // seting the diagonal;
    std::vector<double> M(n * n, 0); // lower triangle;
    for (int j = 0; j <= degree; j++)
        M[j * n + j] = C[degree][j];
    // compute the remainings;
    for (int i = 0; i <= degree; i++)
        for (int j = i + 1; j <= degree; j++)
            M[j * n + i] = ((j + i) & 1 ? -1 : 1) * C[j][i] * M[j * n + j];
    return M;
}
