RANSAC 알고리즘을 써서 주어진 2차원 점집합에서 원을 추정한다. 원을 만들기 위해서는 최소한 3점이 필요하고, 또 일직선에 있지 않아야 한다. 이렇게 만들어진 원은 세 점을 꼭짓점으로 하는 삼각형의 외접원이다. 주어진 외접원에서 크게 벗어나지 않는 inliers를 찾고, 이 inliers에 대해 최소자승법으로 원의 중심과 반지름을 다시 추정한다. 무작위로 선택된 세 점에 대해 위의 과정을 반복 시행해서 구한 원 중에서 inliers의 벗어남 편차가 최소인 것을 결과로 선택한다.
// 참고: http://en.wikipedia.org/wiki/RANSAC
//
// [0, max_num) 사이에서 3개의 숫자를 무작위로 선택함;
void GetRandomTriplet(int max_num, int triplet [3]);
// 세 점의 외접원을 구함;
int CircumCircle(double tx[3], double ty[3], double cparams[4]) ;
// 3x3 선형 방정식을 푼다: A * x = b;
bool SolveLinearEQ3x3(double A [9], double bb [3], double x [3]) ;
// x^2 + y^2 + A*x + B*y + C = 0;
// Least square fit for A, B, C;(참조: kipl.tistory.com/207)
int CircleFit_LS(std::vector<double>& xp, std::vector<double>& yp, double cparams[4]) ;
// 주어진 원에서 임계 거리 이내의 데이터만 골라냄;
double findInlier(std::vector<double>& xp, std::vector<double>& yp,
double cparams[4], double dist_th,
std::vector<double>& xinliers, std::vector<double>& yinliers) {
xinliers.clear(); yinliers.clear();
double rms = 0; // root-mean-square;
double cx = cparams[0], cy = cparams[1], rad = cparams[2];
for (int k = xp.size(); k-->0;) {
double dist_dev = fabs(hypot(xp[k]-cx, yp[k]-cy)-rad)/rad ;
if (dist_dev <= dist_th) { // collect maybe_inliers;
xinliers.push_back(xp[k]);
yinliers.push_back(yp[k]);
rms += SQR(dist - rad);
}
}
return sqrt(rms / xinliers.size());
}
int RansacCircleFit(std::vector<double>& xp, std::vector<double>& yp,
int sample_th, // # of inliers; >= 50% of data(N), 66%;
double dist_th, // 25% of radius; |dist-rad|/rad< dist_th
int max_iter,
double cparams[4]) {
double pr = double(sample_th) / double(xp.size());
double trials99 = log(1. - 0.99)/log(1. - pow(pr, 3));
int iter = min(max_iter, trials99);
bool found = false;
double min_rms = 1.e+10;
double cx, cy, rad;
if (sample_th < 3) sample_th = 3;
while (iter--) {
int tri[3];
double tx[3], ty[3];
getRandTriple(xp.size()-1, tri);
for (int i = 0; i < 3; i++)
tx[i] = xp[tri[i]], ty[i] = yp[tri[i]];
if (!circumCircle(tx, ty, cparams)
// if three points are degenerate or on a line, discard them!
continue ;
std::vector<double> consensusx, consensusy;
sdev = findInlier(xp, yp, cparams, dist_th, consensusx, consensusy);
if (consensusx.size() >= sample_th) {
// estimate model params using the maybe-inliers;
if (!circleFit_LS(consensusx, consensusy, cparams))
continue; // least-square fitting fails;
// collect real-inliers;
double rms = findInlier(xp, yp, cparams, dist_th/2, consensusx, consensusy);
if (consensusx.size() < sample_th) continue;
// estimate model params using inliers again;
if (!circleFit_LS(consensusx, consensusy, cparams)) continue;
TRACE("cx = %f, cy = %f, rad=%f\n", cparams[0], cparams[1], cparams[2]);
if (rms < min_rms) {
min_rms = rms; found = true;
// we need more elaborate termination conditions;
#if _DEBUG
#endif
}
}
}
return found;
};
- sample_th = 2 * N / 3;
- dist_deviate_th = 0.25;
- 파란색: 최소자승법을 이용한 피팅 (outlier의 영향을 많이 받음);
- 붉은색: RANSAC 피팅 결과 (2017.01.04 수정)
see also http://blog.naver.com/helloktk/80029898273
